350kW High Power Charger 350kW DC Charger CCS2 High Power Charger 350kW DC Charger

Short Description:

Product category: DC-DC EV Charger

Connector Stadard: CCS/GBT

Output power: 60-240KW

Max output current(A): 300A

Frequency: 55Hz±10%

Power factor: ≥0.99

Send email to us

Product Detail

Product Tags

350kW DC EV Charger Fast Charging Station CCS2 High Power Charger 350kW DC Charger

High Power Charger 350kw DC Charger
MIDA High Power Charger 350kW offers the fastest charging time than any other charger.lt is ideally suited in highway rest stops, traditional fuel stations and fleet charging due to its high power of up to 350kW, equal load distribution and simultaneous charging features charging 2 vehicles at a time.
High power efficiency and the ability to share power from the power cabinet between two dispensers enable to reduce cost of ownership. lt also offers a user-friendly desian with an LED status light visible from a distance and a 15-inch display. MIDA High Power charger 350kW helps EV drivers shorten the time getback on the road. And we use a higher power Cable, to make sure that the car can still get the high power even if the car don’t support 1000V.

Machine	Dimension(WDH)	700mm700mm1800mm	Class of protection	IP54（Outdoors）
	Equipment weight	About:390kg	Cooling	Forced air cooling
	Module weight	About:17kg	Cable length	5m(Customizable)
	Installation type	Floor type
Input	Ac input voltage	AC400V±10％	Grid frequency	45Hz to 65Hz
	Phase lines	L1、L2、L3、N、PE	Power factor	≥0.98
	Current:THD	<5%
Output	Output power	DC240KW	Efficiency	≥95%
	Output voltage	DC150V to 1000V	Measure	Dc meter
	Output current	Single gun:DC0 to 300A
Environment	Humidness	5％ to 95％	Altitude	≤2000m
	Storage TEMP	-40℃ to +70℃
	Operating TEMP	-30℃ to 50℃ （50℃ to 70℃ Derated output）
Screen	Reveal	10in Display
	Scram	Press to stop
	Starting mode	Plug and charge, swipe card, scan code (optional)
	Billing mode	Automatic charging fixed power fixed amount fixed time (optional)
