DC 360kW Ultra Fast EV Charger Station Manufacturer

Short Description:

Product category: DC-DC EV Charger

Connector Stadard: CCS/GBT
Output power: 60-240KW
Max output current(A): 300A
Frequency:  55Hz±10%
Power factor:  ≥0.99

Product Detail

Product Tags



DC 360kW Ultra Fast EV Charger Station Manufacturer





DC charging voltage refers to the electrical potential that powers the charging process in electric vehicles. Unlike Alternating Current (AC) charging, which is commonly used for home charging, DC charging offers faster and more efficient charging solutions for EVs. The DC charging voltage is typically higher than the voltage used for AC charging.



Electric vehicle charging stations that provide DC charging are equipped with substantial power output capabilities to ensure a swift and convenient charging experience for EV owners. The DC voltage is directly connected to the vehicle’s battery, delivering power at high speeds, significantly reducing charging time compared to AC charging.





240kw dc charging station

Machine

Dimension(W*D*H)

700mm*700mm*1800mm

Class of protection

IP54(Outdoors)

Equipment weight

About:390kg

Cooling

Forced air cooling

Module weight

About:17kg

Cable length

5m(Customizable)

Installation type

Floor type

Input

Ac input voltage

AC400V±10%

Grid frequency

45Hz to 65Hz

Phase lines

L1、L2、L3、N、PE

Power factor

≥0.98

Current:THD

<5%

Output

Output power

DC240KW

Efficiency

≥95%

Output voltage

DC150V to 1000V

Measure

Dc meter

Output current

Single gun:DC0 to 300A

Environment

Humidness

5% to 95%

Altitude

≤2000m

Storage TEMP

-40℃ to +70℃

Operating TEMP

-30℃ to 50℃ 50℃ to 70℃ Derated output)

Screen

Reveal

10in Display

Scram

Press to stop

Starting mode

Plug and charge, swipe card, scan code (optional)

Billing mode

Automatic charging fixed power fixed amount fixed time (optional)
