Level 3 DC charger ETL/UL certificated DC Charger CCS1 + Tesla DC Fast Charger

Short Description:

Product category: DC Charger with CCS/GBT/CHAdeMO connectors

Connector Stadard: CCS/GBT

Output power: 240KW

Max output current(A): 300A

Frequency: 55Hz±10%

Power factor: ≥0.99

Send email to us

Product Detail

Product Tags

Level 3 DC charger ETL/UL certificated DC Charger CCS1 + Tesla DC Fast Charger

This charging pile is an integrated fast charging device for electric vehicles. It integrates functions such as charging modules, charging control, metering and billing, and communication. It can flexibly control charging according to the vehicle’s charging needs and meet the requirements of DC fast charging in multiple scenarios. This design significantly reduces charging time and is ideal for public charging stations and highway service areas ‌.

Machine	Dimension(WDH)	700mm700mm1800mm	Class of protection	IP54（Outdoors）
	Equipment weight	About:390kg	Cooling	Forced air cooling
	Module weight	About:17kg	Cable length	5m(Customizable)
	Installation type	Floor type
Input	Ac input voltage	AC400V±10％	Grid frequency	45Hz to 65Hz
	Phase lines	L1、L2、L3、N、PE	Power factor	≥0.98
	Current:THD	<5%
Output	Output power	DC240KW	Efficiency	≥95%
	Output voltage	DC150V to 1000V	Measure	Dc meter
	Output current	Single gun:DC0 to 300A
Environment	Humidness	5％ to 95％	Altitude	≤2000m
	Storage TEMP	-40℃ to +70℃
	Operating TEMP	-30℃ to 50℃ （50℃ to 70℃ Derated output）
Screen	Reveal	10in Display
	Scram	Press to stop
	Starting mode	Plug and charge, swipe card, scan code (optional)
	Billing mode	Automatic charging fixed power fixed amount fixed time (optional)
