Level 3 Fast Charging Station CCS1 NACS DC EV OCPP 1.6 Commercial Use OCPP2.0 With POS Machine 350kw 480kw

Product category: CCS1 NACS DC EV Charger

Connector Stadard: CCS1/NACS

Output power: 360KW

Max output current(A): 500A

Frequency: 55Hz±10%

Power factor: ≥0.99

Send email to us

Product Detail

High power: 350 kW and 480 kW models for very fast charging of EVs and light commercial EVs.
Dual-standard connectors: CCS1 + NACS (one or two guns configurable).
Backend protocols: OCPP 1.6 + OCPP 2.0 (both supported; 2.0 for richer device management & telemetry).
On-device payment: Integrated POS terminal (EMV chip + contactless NFC + magnetic stripe optional) with PCI-compliant payment flow and OCPP-based transaction reporting.
Cooling: Liquid-cooled DC cables (standard) for sustained high-power charging; optional air-cooled variant for lower cost/weight.
Robust: IP54/IP55 (outdoor) enclosure option, wide operating temperature range, built-in protections (overcurrent, short-circuit, overvoltage, ground fault, surge).
Smart features: Dynamic Load Management (DLM), scheduleable tariffs, user authentication (RFID / mobile / Plug&Charge with ISO 15118 optional), firmware OTA, remote diagnostics.
Compliance options: CE / UL / IEC standards support; ISO 15118 Plug & Charge optional module.

Machine	Dimension(WDH)	700mm700mm1800mm	Class of protection	IP54（Outdoors）
	Equipment weight	About:390kg	Cooling	Forced air cooling
	Module weight	About:17kg	Cable length	5m(Customizable)
	Installation type	Floor type
Input	Ac input voltage	AC400V±10％	Grid frequency	45Hz to 65Hz
	Phase lines	L1、L2、L3、N、PE	Power factor	≥0.98
	Current:THD	<5%
Output	Output power	DC240KW	Efficiency	≥95%
	Output voltage	DC150V to 1000V	Measure	Dc meter
	Output current	Single gun:DC0 to 300A
Environment	Humidness	5％ to 95％	Altitude	≤2000m
	Storage TEMP	-40℃ to +70℃
	Operating TEMP	-30℃ to 50℃ （50℃ to 70℃ Derated output）
Screen	Reveal	10in Display
	Scram	Press to stop
	Starting mode	Plug and charge, swipe card, scan code (optional)
	Billing mode	Automatic charging fixed power fixed amount fixed time (optional)
