DCDC Power Module 20KW EV Charging Module

Short Description:

Model Number: TH20F10025C7

Type: charging module
Place of Origin: China
Input voltage rage(AC): 285~475
Output voltage-adjustment range(DC): 150~1000
Working temp range: -30~+75℃
Above 1/3 load efficiency: ≥95.6%
High power factor: full load≥ 0.99
Low THD: full load≤ 5%
Low standby power loss: <13W
Output constant power function: 1000-250VDC 20KW

Product Detail

Product Tags

30kw Charging Module

EVC1000-20000B Series High frequency switch DCDC modules are DC voltage input and DC
voltage output adjustable DCDC modules.The module adopts DSP digital control, MPPT control,
resonant soft switch, and has a number of patent protection;The module has the characteristics of
high power density, high power factor, small harmonics, high efficiency, and multi-module can be
parallel performance.
2 Main features
 High efficiency
Reduce energy consumption, meet the requirements of energy conservation and
emission reduction, save electricity for customers.
 High power density
Saves customer space and reduces system costs.
 DSP digital control
Fewer devices, higher environmental stability, higher reliability, more
convenient expansion.
 Wide input voltage range, wide output voltage range
Suitable for most different input and output voltage occasions.
 Wide operating temperature range
Wide operating temperature range meets most harsh operating environments
 Built-in anti-reverse protection, with failure self-isolation function
Greatly improve system reliability.
 Perfect fault self-detection prompt
